The new ATX is ideal for all those who want to ride through life boldly. Thanks to outstanding agility and rigidity of the unique multi-geometrical extruded cross bars. Special features of this “extreme design” include a compact dimensions with rigid structure. Foot plate angles are fully adjustable allowing the legs to be positioned at any desired angle. The is the result of years of research and development. The unique tubes, welding, and components are precisely optimized to achieve the highest strength to weight ratio. Every frame is adjusted by our master tech to your order specification. We can now improve sufficient stability for larger and stronger users while avoiding excess weight for smaller and lighter users. The S-ERGO ATX transfers your energy to the street with ultimate style, comfort, and expression.
Highlights
- Max User Weight: 275 lbs
- Frame weight 15.4 lbs.
- Ergonomic active wheelchair design
- Folding frame with rigid collapsing mechanism
Specification
Seat Width | 14 inch., 16 inch., 18 inch. |
Seat Depth | 16 inch., 18 inch. |
Armrest Height | 8.5 inch. |
Front Seat Height | 17 inch., 18 inch., 19 inch., 20 inch. |
Rear Seat Height | 16 inch., 17 inch., 18 inch., 19 inch. |
Back Cane Angle | 85°, 90°, 95° |
Overall Height | 29-38 inch. (dependent on seat height & options) |
Overall Open Width | 21 inch., 23 inch., 25 inch. |
Folded Width | 14 inch. |
Overall Length | 36 inch. |
Weight With Standard Options | 26 – 30 lbs |
Weight Capacity | 275 lbs. |
Shipping Dimensions | 38″ L x 32″ H x 16″ W |
Weight | 40 lbs |
Dimensions | 38 × 16 × 32 in |
Product Weight | 19.1 lbs or less, 25.1 lbs – 35 lbs |
Seat Size | 14" Seat, 16" Seat, 18" Seat |
